ACCO Wire Rope Hoists

WIRE ROPE HOISTS

Acco’s Wright® product line has been the industry leader in establishing hoist duty ratings and has made certain their hoists meet this criteria.

The Wright Work-Rated hoists are duty service classification H4. Hoists in this category are capable of high volume handling of heavy loads. Operating 30 minutes of each hour with a maximum of 300 starts an hour. Wright Work-Rated hoists meet ASME-4M, both mechanically and electrically.

Work-Rated Hoists include features like:

  • 30-minute Duty Motors
  • Long Lifts up to 206 feet
  • Mechanical Load Brake
  • Overload Cutoff
  • Single, Two Speed or VFD Controls
  • Motor Brake
  • Motor Thermostat
  • Other options are available

Wright® Work-Rated® Hoists offer options for hazardous locations, spark resistant and explosion resistant hoists.

STANDARD FEATURES

  • Choose 1, 2, 3, 5, 7-1/2, 10, 15, 20- & 25-Ton Capacity
  • Standard Speeds and Lifts Readily Available
  • Choose Lug, Plain, Geared or Motorized Trolley, Deck Mounted or Top Running Trolley
  • Standard Trolley Speeds Readily Available
  • Single and Double Reeved Models Available
  • H4 Duty Class
  • Single or Two Speed Motors
  • Choose 208V, 230V, 460V, 575V
  • Motor Thermostats
  • Overload Cutoff
  • Mechanical Load Brake
  • Motor Brake
  • Hook Travel Upper Gravity Limit Switch
  • 115V Control Circuit
  • NEMA 3R Enclosure
  • Machine Cut, Case Hardened, Alloy Steel Gears
  • Machined Steel Sheaves
  • Largest Oil Bath in Industry
  • Oil Sight Gauge on Housing Cover
  • Rugged, Fluted Aluminum Alloy Housing & Cover
  • Complies with ASME B30.16 and ASME HST-4M Standards

OPTIONS

  • Lifts Longer Than Cataloged Available on Application • Geared Limit Switch
  • Motor Fuse Holders and Fuses
  • Variable Speed by Inverter Control
  • Models for Hazardous Locations. Class I & II, Group C, D, E, F & G, Division I & II
  • Bullard – Type Hook
  • Trolley Modifications & Speeds
  • Operational on Patented Track
  • Trolley ACM and Brakes
  • Trolley Drop Down Lugs & Bumpers
  • Tagline Tow Arm
  • Epoxy Paints Available on Application
  • Audible or Visual Hoist Overload Indicator • Running Time Meter
  • Other Options Available
